Features: small floor area, flexible installation according to the actual situation, low investment cost, high cost performance, simple and durable operation for the replacement and transformation of old style drying (coal, fuel, firewood, etc.). Normal temperature or low temperature units can be selected.
Application fields: small workshop processing of agricultural and sideline products, food processing, aquatic product processing, tobacco, etc.
烘干类型
分体式开环机组(排湿型)
运行温度范围
-10～43°C
烘干温度范围
10～75°C
产品型号
ZKH-11GL
制热量（Kw）
10.8
输入功率（Kw）
3
运行电流（A）
13.6
电源型式V/ph/Hz
220V/50Hz
压缩机形式
转子
压缩机数量（台）
1
冷媒
R134A
外形尺寸（mm）
内机1440*350*910
（L/M/H）（mm）
外机870*310*700
托盘尺寸（mm）
自选
托盘层数（mm）
z自选
净重（kg）
80/80
额定风量（m³/h）
4000
送风静压（Pa）
120
电加热功率（Kw）
2
除湿量（Kg/h）
11
烘干类型
循环送风式（3P/6P）
运行温度范围
-10～43°C
烘干温度范围
10～75°C
产品型号
ZKH-18GL
制热量（Kw）
8
输入功率（Kw）
5
运行电流（A）
8.8
电源型式V/ph/Hz
380V/3N/50Hz
压缩机形式
涡旋
压缩机数量（台）
1
冷媒
R22
外形尺寸（mm）
内机1440*350*910
（L/M/H）（mm）
外机1120*485*1500
托盘尺寸（mm）
自选
托盘层数（mm）
自选
净重（kg）
80/110
额定风量（m³/h）
8000
送风静压（Pa）
120
电加热功率（Kw）
6
除湿量（Kg/h）
18
| Split open-loop unit (moisture exhaust type) | ||||||
| Drying type | Circulating air supply type | Drying type | Circulating air supply type | |||
| Operating temperature range | —10～43℃ | Operating temperature range | —10～43℃ | |||
| Drying temperature range | 10～75℃ | Drying temperature range | 10～75℃ | |||
| Product model | Company | ZKH-11GL(RF) | Product model | Company | ZKH-18GL(RF) | |
| Heating capacity | Kw | 10.8 | Heating capacity | Kw | 8 | |
| Input power | Kw | 3 | Input power | Kw | 5 | |
| Operating current | A | 13.6 | Operating current | A | 8.8 | |
| Power supply type | V/ph/Hz | 220V/50Hz | Power supply type | V/ph/Hz | 380V/3N～/50Hz | |
| Compressor type | / | rotor | Compressor type | / | vortex | |
| Number of compressors | platform | 1 | Number of compressors | platform | 1 | |
| Refrigerant | / | R134A | Refrigerant | / | R22 | |
| Overall dimensions | mm | Internal machine 1440 * 350 * 910 | Overall dimensions | mm | Internal machine 1440 * 350 * 910 | |
| （L/M/H） | 870×310×700 | （L/M/H） | 外机1120*485*1500 | |||
| Tray size | mm | Optional | Tray size | mm | Optional | |
| Number of pallet layers | layer | Optional | Number of pallet layers | layer | Optional | |
| Net weight | kg | 80/80 | Net weight | kg | 80/110 | |
| Rated air volume | ㎥/h | 4000 | Rated air volume | ㎥/h | 8000 | |
| Static pressure of air supply | Pa | 120 | Static pressure of air supply | Pa | 120 | |
| Electric heating power | Kw | 2 | Electric heating power | Kw | 6 | |
| Dehumidification capacity | Kg/h | 11 | Dehumidification capacity | Kg/h | 18 | |
