Heating selling point
One machine for multiple purposes, heating in winter and cooling in summer
Patented defrosting technology, more stable heating supply
The outlet water temperature can still reach 50 °C in the low temperature environment, which not only meets the requirements of floor heating and wind plate heating water temperature, but also meets the requirements of radiator heating water temperature
Modular design to meet different heating needs
Twelve major protection functions, fault self-diagnosis and information prompt, after-sales maintenance is faster and more convenient
Environmentally friendly refrigerant is used to have zero emissions to the atmosphere
Using air enthalpy increase technology, stable operation above -30 °C, and low operating noise;
Suitable for: sub-household and central heating fields, (such as homes, schools, governments, hospitals, factories, hotels, villas, beauty salons, etc.) North and south universal
Technical parameters of heating-frequency conversion low-temperature cold and warm water circulation | ||
Product model | DKZCN-14/DF | |
Rated working condition (7℃) | Heating capacity | 14000W |
Input power/current | 4200W/19.1A | |
COP | 3.33W/W | |
Nominal working condition (-12℃) | Heating capacity | 9500W |
Input power/current | 4112W/19.3A | |
COP | 2.31W/W | |
IPLV(H) | 2.71W/W | |
Refrigeration condition (35℃) | Refrigerating capacity | 10600W |
Input power/current | 4223W/19.7A | |
COP | 2.51W/W | |
Power specifications | 220V/50Hz | |
Operating temperature range | -30~43℃ | |
cryogen | R410A | |
Waterway interface | DN25(内牙) | |
discharge | 1.64m3/h | |
Heat exchanger | Water side | Heat exchange of casing |
Windward side | Finned heat exchanger | |
noise | ≤65dB(A) | |
Fan type | Axial flow fan × two | |
Air outlet form | be born of a concubine | |
Overall dimensions | one thousand and thirty × three hundred and eighty × 1330mm (including footing) | |
Net weight | 112kg | |
Rated working condition: under the ambient temperature of 7 ℃/6 ℃ and the effluent temperature of 45 ℃; Nominal working condition: under the ambient temperature of - 12 ℃/- 14 ℃, the water temperature is 41 ℃; Refrigeration working condition: under the ambient temperature of 35 ℃, the water temperature is 7 ℃; The above parameters are for reference only, see the nameplate of the product body for details |
